Toolholder Selection Guide
C-Style Clamping
C
Top clamping system
for negative and positive
indexable inserts to DIN
4968. This universal
clamping system is
robust and easy to handle.
Some height-adjustable
clamps enable the use of
additional chipbreakers.
A carbide shim provides
additional tool protection.
Toolholders with cutting
edge heights upwards
of 16mm and insert iCs
greater than 6,35mm.
CCLN-MX
95°
Page:
C31
CDJN-MN
93°
Page:
C33
CRDN-MN
Page:
C35
CSSP
45°
Page:
C37
CTGP
90°
Page:
C39
*Exact Clamping System not shown.
S-Style Clamping
S
Screw clamping system
for positive indexable
inserts with countersunk
hole to DIN 4967.
Compact design using
a minimum of spare
parts for high reliability
and cost efficiency.
A carbide shim
provides additional tool
protection. Toolholders
with cutting edge
heights upwards of
16mm and insert iCs
from 9,52mm are secured
by means of a threaded
bushing.
SCLC
95°
Page:
C42
SDJC
93°
Page:
C44
SSSC
45°
Page:
C47
SVVB
72,5°
Page:
C49
CCLN-MN
95°
Page:
C31
CELN-MF
97,5°
Page:
C33
CRSN-MN
Page:
C35
CTCP
90°
Page:
C37
CRDP*
Page:
C40
SCDP
45°
Page:
C42
SDNC
62,5°
Page:
C45
STFC
90°
Page:
C48
