P-Style Clamping Toolholders for Negative Inserts
See pages B68–B80
for inserts.
PSBN 75°
order number catalogue number H B F L1 L2 FA
gage
insert
right hand
3879324
PSBNR2020K12 20 20 17,0 125 26,0 3,1 SN..120408
3900158
PSBNR2525M12 25 25 22,0 150 26,0 — SN..120408
3879333
PSBNR2525M15 25 25 22,0 150 36,0 3,8 SN..150612
3879330
PSBNR3232P15 32 32 27,0 170 33,0 3,8 SN..150612
3879327
PSBNR3232P19 32 32 27,0 170 40,0 4,6 SN..190612
3879334
PSBNR4040S19 40 40 35,0 250 38,0 4,6 SN..190612
3879331
PSBNR4040S25 40 40 35,0 250 47,0 5,9 SN..250724
left hand
3879325
PSBNL2020K12 20 20 17,0 125 26,0 3,1 SN..120408
3900157
PSBNL2525M12 25 25 22,0 150 26,0 — SN..120408
3879329
PSBNL2525M15 25 25 22,0 150 36,0 3,8 SN..150612
3879332
PSBNL3232P15 32 32 27,0 170 33,0 3,8 SN..150612
3879328
PSBNL3232P19 32 32 27,0 170 40,0 4,6 SN..190612
3879323
PSBNL4040S19 40 40 35,0 250 38,0 4,6 SN..190612
3879326
PSBNL4040S25 40 40 35,0 250 47,0 5,9 SN..250724
3900159
PSBNL5050T25 50 50 43,0 300 50,0 — SN..250724
shim
512.063
512.063
512.025
512.025
512.083
512.083
512.092
512.063
512.063
512.025
512.025
512.083
512.083
512.092
512.092
shim
pin
513.023
513.023
513.025
513.025
513.033
513.033
513.038
513.023
513.023
513.025
513.025
513.033
513.033
513.038
513.038
punch
pin
515.018
515.018
515.022
515.022
515.022
515.022
515.028
515.018
515.018
515.022
515.022
515.022
515.022
515.028
515.028
lever
511.023
511.023
511.025
511.025
511.033
511.033
511.038
511.023
511.023
511.025
511.025
511.033
511.033
511.038
511.038
lever
screw
514.123
514.123
514.125
514.125
514.133
514.133
514.138
514.123
514.123
514.125
514.125
514.133
514.133
514.138
514.138
Torx
Plus
15 IP
15 IP
15 IP
15 IP
25 IP
25 IP
30 IP
15 IP
15 IP
15 IP
15 IP
25 IP
25 IP
30 IP
30 IP
