C-Style Clamping Toolholders for Negative Inserts
See pages B177–B179 and
B197–B205 for inserts.
CCLN-MX 95°
order number catalogue number H B F L1 L2
gage
insert
right hand
3032691
3032713
CCLNR2525M12MX7 25 25 32,0 150 32,0 CN.X120708
CCLNR3225P12MX7 32 25 32,0 170 32,0 CN.X120708
left hand
3032692
CCLNL2525M12MX7 25 25 32,0 150 32,0 CN.X120708
NOTE: MX — clamping version is shown.
shim
552.221
552.221
552.221
shim
screw
clamp
hex assembly hex
554.252
554.252
2.5 mm
2.5 mm
551.316
551.316
4 mm
4 mm
554.252 2.5 mm 551.316 4 mm
See pages B177–B179 and
B197–B205 for inserts.
CCLN-MN 95°
order number catalogue number H B F L1 L2
gage
insert
right hand
3032715 CCLNR2525M12MN4 25 25 32,0 150 32,0 CN.N120408
3032717 CCLNR2525M12MN7 25 25 32,0 150 32,0 CN.N120708
3032719
CCLNR3225P12MN7 32 25 32,0 170 32,0 CN.N120708
left hand
3032716
CCLNL2525M12MN4 25 25 32,0 150 32,0 CN.N120408
NOTE: MX — clamping version is shown.
shim
552.220
552.221
552.221
552.220
shim
screw
hex
554.252
554.252
554.252
2.5 mm
2.5 mm
2.5 mm
554.252 2.5 mm
thrust
plate
clamp
assembly hex
557.111
557.111
—
551.317
551.317
551.317
4 mm
4 mm
4 mm
557.111 551.317 4 mm
