C-Style Clamping Toolholders for Negative Inserts
See pages B183–B185
and B210 for inserts.
CRDN-MN
order number catalogue number H B F L1 L2
gage
insert
3032549 CRDNN2525M12MN4 25 25 12,5 150 30,0 RN.N120400
3032551 CRDNN2525M12MN7 25 25 12,5 150 30,0 RN.N120700
3032550 CRDNN3225P12MN4 32 25 12,5 170 30,0 RN.N120400
3032552
CRDNN3225P12MN7 32 25 12,5 170 30,0 RN.N120700
NOTE: MN — clamping version is shown.
shim
552.229
552.230
552.229
552.230
shim
screw
554.252
554.252
554.252
554.252
hex
2.5 mm
2.5 mm
2.5 mm
2.5 mm
thrust
plate
557.111
557.111
557.111
557.111
clamp
assembly hex
551.333 4 mm
551.333 4 mm
551.333 4 mm
551.333 4 mm
See pages B183–B185
and B210 for inserts.
CRSN-MN
order number catalogue number H B F L1 L2
gage
insert
right hand
3032677
3032675
CRSNR2525M12MN7 25 25 32,0 150 26,0 RN.N120700
CRSNR3225P12MN4 32 25 32,0 170 26,0 RN.N120400
3032679
CRSNR3225P12MN7 32 25 32,0 170 26,0 RN.N120700
left hand
3032678
CRSNL2525M12MN7 25 25 32,0 150 26,0 RN.N120700
3032676
3032680
CRSNL3225P12MN4 32 25 32,0 170 26,0 RN.N120400
CRSNL3225P12MN7 32 25 32,0 170 26,0 RN.N120700
NOTE: MN — clamping version is shown.
shim
552.230
552.229
552.230
552.230
552.229
552.230
shim
screw
hex
554.252
554.252
554.252
2.5 mm
2.5 mm
2.5 mm
554.252
554.252
554.252
2.5 mm
2.5 mm
2.5 mm
thrust
plate
557.111
557.111
557.111
557.111
557.111
557.111
clamp
assembly hex
551.333
551.333
551.333
4 mm
4 mm
4 mm
551.333
551.333
551.333
4 mm
4 mm
4 mm
