S-Style Clamping Boring Bars for Positive Inserts
Steel Shank with Through Coolant
Steel shank with
through coolant.
See pages B47–B64
for inserts.
A-SDUC 93°
order number catalogue number D D min F L1 A
gage
CS aF° insert
shim
shim
screw hex
right hand
3883297
A10KSDUCR07 10 13,0 7,0 125 3,2
—
-7.0 DC..070204
—
——
3883294
3883293
A16RSDUCR07
A16RSDUCR11
16 20,0 11,0 200 — 1/8-27 NPT -4.0 DC..070204
16 20,0 11,0 200 — 1/8-27 NPT -6.0 DC..11T308
—
—
——
——
3883291
A20SSDUCR11 20 25,0 13,0 250 — 1/8-27 NPT -5.0 DC..11T308
—
——
3883288
3883287
A25TSDUCR11
A32TSDUCR15
25 32,0 17,0 300 — 1/8-27 NPT -4.0 DC..11T308
—
——
32 40,0 22,0 300 — 1/8-27 NPT -7.0 DC..150408 SKDP453 SRS4 4 mm
left hand
3883298
3883296
A10KSDUCL07
A16RSDUCL07
10 13,0 7,0 125 3,2 — -7.0 DC..070204
16 20,0 11,0 200 — 1/8-27 NPT -4.0 DC..070204
—
—
——
——
3883295
3883292
A16RSDUCL11
A20SSDUCL11
16 20,0 11,0 200 — 1/8-27 NPT -6.0 DC..11T308
20 25,0 13,0 250 — 1/8-27 NPT -5.0 DC..11T308
—
—
——
——
3883290
A25TSDUCL11 25 32,0 17,0 300 — 1/8-27 NPT -4.0 DC..11T308
—
——
3883289
A32TSDUCL15 32 40,0 22,0 300 — 1/8-27 NPT -7.0 DC..150408 SKDP453 SRS4 4 mm
insert
screw
MS1153
MS1153
MS1155
MS1155
MS1155
MS1158
MS1153
MS1153
MS1155
MS1155
MS1155
MS1158
Torx
T7
T7
T15
T15
T15
T15
T7
T7
T15
T15
T15
T15
