C-Style Clamping Cartridges for Positive Inserts
See pages B186–B191 and
B211–B212 for inserts.
CSSP 45°
order number
catalogue number
D min
F
L1 FA L1A hS° aO°
gage
insert
right hand
3870430
CSSPR10CA09
40,0 14,0 44 6,5 6,1 0.0 0.0 SP..090308/SP..322
3870429
CSSPR12CA12
50,0 20,0 47 8,7 8,3 0.0 0.0 SP..120308/SP..422
left hand
3870433
CSSPL10CA09
40,0 14,0 44 6,5 6,1 0.0 0.0 SP..090308/SP..322
3870432
CSSPL12CA12
50,0 20,0 47 8,7 8,3 0.0 0.0 SP..120308/SP..422
3870431
CSSPL20CA12
70,0 25,0 60 — 8,3 0.0 0.0 SP..120308/SP..422
Spare Parts
D min
40
50
70
shim
—
—
SM840
shim
screw
—
—
MS111
hex
—
—
2 mm
clamp
CKM34
CKM34
CKM20
clamp
screw
STCM38
STCM38
STCM11
hex
2 mm
2 mm
3 mm
radial
adjusting
screw
KUAM28
KUAM22
KUAM26
hex
2 mm
2 mm
3 mm
axial
adjusting
screw
KUAM30
KUAM31
KUAM32
mounting
screw
191.405
191.406
191.407
hex
4 mm
4 mm
5 mm
washer
CSWM 060 050
CSWM 060 050
CSWM 080 050
Effective Width
Chipbreakers for C-Style Cartridges
Chipbreakers
insert
SP..090308/SP..322
SP..120308/SP..422
chipbreaker
CBS-12
CBS-12D**
CBS16
CBS-16D**
CBS-16N
CBS16F
effective
width
2.1
2.1
4.4
2.8
3.0
2.1
note
**For chipbreaking on both primary and secondary cutting edges
**For chipbreaking on both primary and secondary cutting edges
C108
