C-Style Clamping Cartridges for Positive Inserts
See pages B192–B194 and
B212–B216 for inserts.
CTFP 90°
order number
catalogue number
D min
F
L1 aF° aP°
gage
insert
right hand
3870427
CTFPR10CA11
40,0 14,0 50 0.0 5.0 TP..110304/TP..421
3870426
CTFPR12CA16
50,0 20,0 55 0.0 5.0 TP..160308/TP..322
3870424
CTFPR20CA22
70,0 25,0 70 0.0 5.0 TP..220408/TP..432
left hand
3870428
CTFPL12CA16
50,0 20,0 55 0.0 5.0 TP..160308/TP..322
Spare Parts
D min
40
50
70
shim
—
—
SM837
shim
screw
—
—
MS125
clamp
CKM34
CKM34
CKM35
clamp
screw
STCM38
STCM38
STCM8
hex
2 mm
2 mm
4 mm
radial
adjusting
screw
KUAM28
KUAM22
KUAM25
hex
2 mm
2 mm
2.5 mm
axial
adjusting
screw
KUAM30
KUAM31
KUAM32
mounting
screw
191.405
191.406
191.407
hex
4 mm
4 mm
5 mm
washer
CSWM 060 050
CSWM 060 050
CSWM 080 050
Effective Width
Chipbreakers for C-Style Cartridges
Chipbreakers
insert
TP..110304/TP..421
TP..160308TP..322
TP..220408/TP..432
chipbreaker
CBT-8
CBT-12*
CBT-12*
CBT-12*
CBT-16
CBT-16N
CBT-16F
effective
width
2.2
4.0
2.7
2.2
5.5
3.2
2.1
zakaz@widiahanita.ru
www.widiahanita.ru
note
*Use with CTC-style holder only
*Use with CTC-style holder only
*Use with CTC-style holder only
C109
