Small Hole Boring
Catalogue Numbering System
для размещения заказа - zakaz@widiahanita.ru
A/B Series Boring Bar Identication System
ABD
Insert Style
A Series = Through Coolant
ABC = Indexable Boring
ABD = Boring
AGD = Grooving
APD = Profiling
ATD = Threading
B Series = Without Coolant
BB = Boring
BP = Profiling
ABD125375R
125
Minimum Bore
shown as “D min”
375
Bore Depth, Groove Width,
Flat on Thread
shown as “L4, W”
R
Hand
of Tool
A Series
06 = 1,58mm
09 = 2,39mm
125 = 3,18mm
156 = 3,96mm
(AGD style only)
095 = 2,79mm
125 = 3,56mm
156 = 4,45mm
(ATD style only)
095 = 2,79mm
125 = 3,56mm
156 = 4,45mm
B Series
187 = 4,75mm
250 = 6,35mm
312 = 7,93mm
Bore Depth
A Series
187 = 4,75mm
281 = 7,14mm
312 = 7,93mm
375 = 9,53mm
500 = 12,70mm
600 = 15,24mm
625 = 15,88mm
750 = 19,05mm
825 = 20,96mm
875 = 22,23mm
1000 = 25,40mm
1250 = 31,75mm
1500 = 38,10mm
1750 = 44,45mm
2125 = 53,98mm
Groove Width
(AGD style only)
03 = 0,76mm
04 = 1,02mm
05 = 1,27mm
Thread
(ATD style only)
F2 = 0,05mm
Flat on thread
R=
Right hand
L=
Left hand
Tip Style
(optional)
Symbol
M
Usage
Mini tip
