WIDIA™ Victory™ • High-Performance Inserts
Grades and Grade Descriptions
Coatings provide high-speed
capability and are engineered
for nishing to heavy roughing.
P Steel
M Stainless Steel
K Cast Iron
N Non-Ferrous
S High-Temp Alloys
H Hardened Materials
Coating
Grade Description
HC-K05
Coated carbide. MT-CVD/CVD — TiN-TiCN-Al2O3. Increased wear resistance
for long tool life at high cutting speeds. Enhanced edge strength against
depth-of-cut notching in interrupted cuts. Maximum wear resistance for long
tool life at high cutting speeds in finish to medium machining.
Coated carbide. MT-CVD/CVD — TiN-TiCN-Al2O3. First choice for a wide range
of machining on all grey and ductile irons, light to heavy machining, smooth
or interrupted cuts, and wet or dry.
wear
resistance
toughness
05 10 15 20 25 30 35 40 45
P
K
P
K
HC-K20
HC-S10
HC-S25
An advanced multilayer PVD coating over a very deformation-resistant unalloyed
carbide substrate. The new and improved coating improves edge stability with
wide range speed and feed capabilities. WS10PT™ is ideal for finishing to general
machining of most workpiece materials at a wide range of speed and feed
capabilities. Excellent for machining most steels, stainless steels, cast irons,
non-ferrous materials, and super alloys with improved edge toughness and
higher cutting speed and feed capabilities.
An advanced PVD grade with hard AlTiN coating and fine-grain unalloyed substrate.
The new and improved coating improves edge stability with wide range speed and
feed capabilities. WS25PT™ is ideal for general machining of most steels, stainless
steels, high-temp alloys, titanium, irons, and non-ferrous materials at moderate
speeds and over a wide range of feeds, with improved edge toughness for interrupted
cut and high feed rates.
P
M
K
N
S
H
P
M
K
N
S
C3-C4
An uncoated, hard, low-binder content, unalloyed WC/Co fine-grain grade.
WU10HT™ offers exceptional edge wear and superior thermal deformation
and depth-of-cut notch resistance. The grain structure is well controlled
for minimal pits and flaws, which contributes to long, reliable service.
M
N
S
