Grooving and Cut-Off Platforms
для размещения заказа - zakaz@widiahanita.ru
Grooving
WMT™
• Insert cutting widths: 2–8mm.
• O.D. cutting depths: 16,5–25,4mm.
• I.D. boring bar minimum bore diameter:
57,15mm.
• Screw-clamping integral shank/cartridge
toolholders available.
• Geometry for deep grooving.
TopGroove™
• Insert cutting widths: 0,5–6,35mm.
• Insert cutting depths: 0,64–12,7mm.
• I.D. boring bar minimum bore diameter:
11,2mm.
• Integral shank toolholders available.
ProGroove™
• Insert cutting depths: 10–40mm.
• Inserts enable precision sintered
execution, good tolerances,
and repeatability.
• Screw-clamping integral shank
toolholders available.
• Grooving and O.D. turning.
Pages:
E4–E39
Pages:
E40–E91
Pages:
E92–E104
LG
• Insert cutting widths: 8–16mm.
• O.D. cutting depths: 20–32mm.
• Wedge-clamping integral shank
tooling available.
Pages:
E105–E107
Cut-Off
WMT
• Cut-off widths: 1,5–4mm.
• Maximum cutting depth: 22,2mm.
• Screw-clamping integral shank/cartridge
toolholders available.
• Economical double-sided inserts for rigidity
and dimensional accuracy.
• Right-/left-hand styles: 5 and 12 lead
angles.
Separator™
• Cut-off widths: 2–4mm.
• Positive mechanical, self-clamping blades.
• Right-/left-hand style toolholders available.
• Single-edge inserts for maximum depth
capacity.
ProGroove
• Cut-off widths: 2–8mm.
• Single-edge inserts for maximum depth
capacity.
• Right-/left-hand styles with 6 lead angles.
• Self-clamping blades/screw-clamping
integral shank toolholders available.
Pages:
E4–E39
Pages:
E108–E133
Pages:
E92–E104
Plunge
and Turn
WMT
Heavy Stock Removal in Turning Applications
• Double-sided inserts, cutting widths: 2–8mm.
• O.D. cutting depths: 16,5–25,4mm.
• I.D. boring bar minimum bore diameter: 57,15mm.
• Screw-clamping integral shank/cartridge toolholders
available.
ProGroove
For Light-Cutting Inserts
• Cutting widths: 2–8mm.
• O.D. cutting depths: 10–40mm.
• Single-edge inserts for maximum depth capacity.
• Screw-clamping integral shank toolholders available.
Pages:
E4–E39
Pages:
E92–E104
E2
