Grooving and Cut-Off Platforms
Face
Grooving
WMT™
• Cutting widths: 3–6,35mm.
• Cutting depths: 13–25,4mm.
• Minimum face groove diameter:
38–205mm.
TopGroove™
• NF/NFD face groove insert range: 24–57mm.
• Cutting width range for standard inserts: 0,8–9,5mm.
• Cutting depth range for standard inserts: 1,27–12,70mm.
• Cutting width range for NF/NFD face grooving inserts: 2–6,35mm.
• Standard insert minimum face groove diameter range: 54–330mm.
• Cutting depth range for NF/NFD face grooving inserts: 1,52–12,70mm.
• Cutting depth range for NF: 1,52–3,81mm.
• Cutting depth range for NFD: 6,35–12,7mm.
Pages:
E4–E39
Pages:
E40–E91
Proling
WMT
For Heavy Stock Removal
• Full-radius insert cutting widths: 3–8mm.
• O.D. cutting depths: 16,5–25,4mm.
• Screw-clamping integral shank/cartridge
toolholders available.
TopGroove
Moderate/Heavy Stock Removal
at Shallow Prole Depths
• Full-radius insert cutting widths:
1,57–6,35mm.
• Insert cutting depths: 2,39–6,35mm.
• Integral shank toolholders and
ERICKSON™ heads available.
ProGroove™
For Light Cutting
• Full-radius insert cutting widths: 3–6mm.
• O.D. cutting depths: 10–32mm.
• Screw-clamping integral shank/cartridge
toolholders available.
Pages:
E4–E39
Pages:
E40–E91
Pages:
E92–E104
Undercutting
TopGroove
• Undercutting insert widths: 2,4–4mm.
• Economical double-ended inserts.
Pages:
E40–E91
