WMT™ Turning, Grooving, and Cut-Off
Catalogue Numbering System
WMT Identication System
Each character in our catalogue number signifies a specific trait of
that product. Use the following key columns and corresponding
images to easily identify which attributes apply.
Cut-Off
WMT
Tooling
System
C
Cut-Off
015
W in
mm* 10
WMTC015N00CM08
N
Hand
of Insert
00
Main Cutting
Edge Lead
Angle
CM
Chipbreaker
Geometry
CM = Cut-Off
Medium
CM-W = Cut-Off
Medium with
Wiper
08
Corner Radius
in mm* 10
Groove, Plunge, Turn, and Contour Inserts
WMT S 205
Tooling
System
Square
mm* 10
inch* 1000
M
Unit of
Measurement
for Width
M = mm
I = inch
WMTS205M2U02PT
2
Seat Size
U
Insert
Tolerance
02
Corner
Radius in
mm* 10
PT
Chipbreaker
Geometry
PT = Groove,
Plunge,
and Turn
PH = Groove,
Plunge,
and Turn
PC = Plunge
and Contour
P = Precision ground grooving
width tolerance:
± .001" (0,025mm)
U = Utility moulded grooving
width tolerance:
3,05–4,05:
+ .006"
-0
(+0,15mm)
-0
5,05–10,05:
+ .010"
-0
(+0,25mm)
-0
E10
