WMT™ Turning, Grooving, and Cut-Off
WMT Modular Toolholders
CD Blade
F
F Assy Holder
FS (Blade)
L1 Holder
L1 Assy
Right Hand Tool
2 blade screws required
F Assy = F (Holder) + FS (Blade) + W/2
L1 Assy = L1 (Holder) + CD (Blade)
Straight Mount • Grooving, Cut-Off, and Face Grooving
order number catalogue number
H
B
right hand
5349628 WGMSR2020 20 20
5349629 WGMSR2525 25 25
5349641 WGMSR3232 32 32
left hand
5349625 WGMSL1620 16 20
5349626 WGMSL2020 20 20
5349627 WGMSL2525 25 25
NOTE5:3U49se64th0e larger seWatGsMizeStLo3o2lh3o2lder for op3ti2mal perform32ance.
NOTE: Use the larger seat size toolholder for optimal performance.
Blade screws and clamp screw included with holder.
L1
108,0
126,0
126,0
108,0
108,0
126,0
126,0
LS
68,00
95,78
69,85
68,00
68,00
95,78
69,85
F
8,84
13,84
20,81
8,84
8,84
13,84
20,81
Torx for
Torx for
blade
blade
clamp clamp
H3
screw
screw
screw
screw
12 MS2002 T25 MS1162 T25
7 MS2002 T25 MS1162 T25
— MS2002 T25 MS1162 T25
16 MS2002 T25 MS1162 T25
12 MS2002 T25 MS1162 T25
7 MS2002 T25 MS1162 T25
— MS2002 T25 MS1162 T25
Toolholder Style
WGMS — Straight Mount
WGME — End Mount
Hand of Holder
Right
Left
Right
Left
Hand of Blade
Right
Left
Left
Right
Grooving and Cut-Off Blades
found on page E38.
E36
Face Grooving Blades found on
page E39.
