WMT™ Turning, Grooving, and Cut-Off
WMT Modular Toolholders
Right Hand Tool
F Holder
F Assy
L1 Holder
L1 Assy
F Assy = F (Holder) + CD (Blade)
L1 Assy = L1 (Holder) + FS (Blade) + W/2
End Mount • Grooving, Cut-Off, and Face Grooving
order number
catalogue number
H
B
L
L1
LS
F H3
right hand
5514979
WGMER2525
25 25 150,3 139,3 125,25 42,75
9
5515021
WGMER3232
32 32 170,3 159,3 145,25 42,75 —
left hand
5514978
WGMEL2525
25 25 150,3 139,3 125,25 42,75
9
5515020
WGMEL3232
32 32 170,3 159,3
145,25
42,75
—
Toolholder Style
WGMS — Straight Mount
WGME — End Mount
Hand of Holder
Right
Left
Right
Left
Hand of Blade
Right
Left
Left
Right
Grooving and Cut-Off Blades
found on page E38.
Face Grooving Blades found on
page E39.
