WMT™ Turning, Grooving, and Cut-Off
WMT Modular Toolholders
Face Grooving
Right Hand Tool
order number
right hand
catalogue number
seat
size D min D max
CD
W
FS
5359150
WMTWGMR313B038-052
3
38,00
52,00
12,70 3,00 11,00
5359151
WMTWGMR316B052-070
3
52,00
70,00
15,88 3,00 11,00
5359154
WMTWGMR416B052-070
4
52,00
70,00
15,88 4,00 10,50
5359152
WMTWGMR316B070-100
3
70,00
100,00 15,88 3,00 11,00
5359155
WMTWGMR416B070-100
4
70,00
100,00 15,88 4,00 10,50
5359153
WMTWGMR319B100-205 3 100,00 205,00 19,05 3,00 11,00
5359156
WMTWGMR419B100-205 4 100,00 205,00 19,05 4,00 10,50
5359157
WMTWGMR522B100-205 5 100,00 205,00 22,00 5,00 10,00
5359158
WMTWGMR622B100-205 6 100,00 205,00 22,00 6,00 10,00
left hand
5359146
WMTWGML616B030-052
6
30,00
52,00
15,88 6,00 10,00
5359134
WMTWGML313B038-052
3
38,00
52,00
12,70 3,00 11,00
5359138
WMTWGML413B038-052
4
38,00
52,00
12,70 4,00 10,50
5359142
WMTWGML516B038-052
5
38,00
52,00
15,88 5,00 10,00
5359135
WMTWGML316B052-070
3
52,00
70,00
15,88 3,00 11,00
5359139
WMTWGML416B052-070
4
52,00
70,00
15,88 4,00 10,50
5359143
WMTWGML519B052-070
5
52,00
70,00
19,05 5,00 10,00
5359147
WMTWGML619B052-070
6
52,00
70,00
19,05 6,00 10,00
5359136
WMTWGML316B070-100
3
70,00
100,00 15,88 3,00 11,00
5359140
WMTWGML416B070-100
4
70,00
100,00 15,88 4,00 10,50
5359144
WMTWGML519B070-100
5
70,00
100,00 19,05 5,00 10,00
5359148
WMTWGML619B070-100
6
70,00
100,00 19,05 6,00 10,00
5359137
WMTWGML319100-205
3 100,00 205,00 19,05 3,00 11,00
5359141
WMTWGML419B100-205
4 100,00 205,00 19,05 4,00 10,50
5359145
WMTWGML522B100-205 5 100,00 205,00 22,00 5,00 10,00
5359149
WMTWGML622B100-205 6 100,00 205,00 22,00 6,00 10,00
NOTE: Blade and clamp screw torque equals 8–10 Nm.
Toolholder Style
WGMS — Straight Mount
WGME — End Mount
Hand of Holder
Right
Left
Right
Left
Hand of Blade
Right
Left
Left
Right
