WMT™ Turning, Grooving, and Cut-Off
WMT Modular Toolholders
Grooving and Cut-Off
order number
right hand
5359127
5359128
5359129
5359130
5359131
5359132
5359133
left hand
5359120
5359121
5359122
5359123
5359124
5359125
5359126
catalogue number
WMTWGMR114S
WMTWGMR213S
WMTWGMR2B16S
WMTWGMR319S
WMTWGMR419S
WMTWGMR522S
WMTWGMR622S
WMTWGML114S
WMTWGML213S
WMTWGML2B16S
WMTWGML319S
WMTWGML419S
WMTWGML522S
WMTWGML622S
NOTE: Blade and clamp screw torque equals 8–10 Nm.
CD
FS W
W1
Right Hand Blade
seat
size CD
W
1
14,00
1,50
2
13,00
2,00
2B
16,50
2,39
3
19,00
3,00
4
19,00
4,00
5
22,00
5,00
6
22,00
6,00
1
14,00
1,50
2
13,00
2,00
2B
16,50
2,39
3
19,00
3,00
4
19,00
4,00
5
22,00
5,00
6
22,00
6,00
FS
11,04
10,81
10,71
10,38
10,00
9,82
9,26
11,04
10,81
10,71
10,38
10,00
9,82
9,26
W1
1,22
1,68
1,88
2,54
3,30
3,66
4,78
1,22
1,68
1,88
2,54
3,30
3,66
4,78
Toolholder Style
WGMS — Straight Mount
WGME — End Mount
Hand of Holder
Right
Left
Right
Left
Hand of Blade
Right
Left
Left
Right
E38
