TopGroove™
Toolholders
NAS
order number catalogue number H B
gage
F L1 L2 B4 CD B3 L3 insert clamp
clamp
screw
right hand
3641667
3641662
NASR1010M2Q
NASR1212M2Q
10,0 10,0 10,0 150 19 9 3,5 2,03 19 N.2R
12,0 12,0 12,0 150 19 9 3,5 — — N.2R
CM182
CM182
MS1200
MS1200
3639048
NASR1616K3Q 16,0 16,0 16,0 125 32 12 5,3 — — N.3R CM184LP
—
left hand
3641691
NASL1010M2Q 10,0 10,0 10,0 150 19 9 3,5 2,03 19 N.2L CM183 MS1200
3641686
3641687
NASL1212M2Q
NASL1616K3Q
12,0 12,0 12,0 150 19 9 3,5 — — N.2L CM183 MS1200
16,0 16,0 16,0 125 32 12 5,3 — — N.3L CM185LP
—
NOTE: F dimension measured over sharp point of insert.
