Separator™ Inserts
Feed Values for Grooving
для размещения заказа - zakaz@widiahanita.ru
Separator • X2 and X2-Ultra
X2
X2-Ultra
This insert has the same geometry as the WMT-SX™. Chip
control geometry offers the widest range of speed and feed
capabilities and provides excellent flatness and finish. This
chipbreaker cuts with the least amount of tool pressure,
extending tool life. The geometry also includes wipers and
a corner radius. This geometry works well on a variety of
materials.
This insert has the same geometry as the WMT-SX-Ultra. The
X2-Ultra is an enhanced version of the X2 and is ideal for stainless
steels, nickel-based alloys, tool steel, INCONEL®, and titanium.
0,30
0,25
0,20
0,15
0,10
0,05
2,0 2,5 3,0
width of cut [mm]
1 Recommended Starting Feed
Separator • S2 and S2-Ultra
S2
S2-Ultra
High positive rake with a more open chipbreaker enables
increased speeds and feeds for moderate- to high-speed
applications. The geometry includes wipers and a corner
radius that provides superior flatness and finish. This insert
is also available with sharp corners. Its greatest strengths
can be seen on stainless steels and soft gummy steels.
The S2-Ultra is an enhanced version of the S2 and is ideal
for 300 series stainless steels, nickel-based alloys, tool steel,
INCONEL, and titanium at moderate to high speeds and feeds.
0,30
0,25
0,20
0,15
0,10
0,05
2,5 3,0 4,0
width of cut [mm]
1 Recommended Starting Feed
Separator • Classic and F2
Classic
F2
A good general-purpose insert for carbon steels, alloy steels,
and most stainless steels. The Separator Classic chipbreaker
is designed to perform well at moderate to slow speeds and
feeds. The Classic provides standard high lead angles and sharp
corners, making it the first choice when choosing an insert for
nib-free cut-off.
This insert provides superior flatness and finish on a wide variety
of materials Ideal for thick wall parts or cutting off larger diameter
parts to centre. The Separator F2 performs well at slow to
moderate speeds and feeds.
0,30
0,25
0,20
0,15
0,10
0,05
1,5 2,5 3,2 4,0
width of cut [mm]
4,8
1 Recommended Starting Feed
