Separator™
Toolholders
для размещения заказа - zakaz@widiahanita.ru
Left Hand Tool
12mm and 20mm Shank Toolholders
Left Hand Tool
Right Hand Tool
order number
right hand
3538772
3614344
left hand
3538773
3538774
catalogue number
206518
206522
206519
206523
H
12,00
20,00
12,00
20,00
B
11,53
20,00
11,53
20,00
B2
24,99
—
24,99
—
L
102,77
102,77
102,77
102,77
L1
84,68
div class="txt" style="position:absolute; left:336px; top:321px;">84,68
84,68
84,68
H2
19,05
—
19,05
—
F
20,55
15,55
20,55
15,55
support blade
screw
606247
606247
606247
606247
clamp
screw
MS1495
MS1495
MS1495
MS1495
Support Blade Assembly
Right Hand Tool
12mm and 20mm Shank Blades
L1 Blade
FS Holder
L1 Holder
L1 Assy
F Assy
FS Blade
L1 Assy = L1 (Holder) + L1 (Blade)
F Assy = F (Holder) + FS (Blade) + W/2
order number
catalogue number
W
D max
FS
L
L1
right hand
3539515
333101
2,50 41,28 3,25 44,88 40,13
3539516
333102
3,00 41,28 2,84 44,88 40,13
3539522
333111
2,00 41,28 3,40 44,88 40,13
left hand
3539517
3539518
333103
333104
2,50 41,28 3,25 44,88 40,13
3,00 41,28 2,84 44,88 40,13
NOTE: Clamps do not ship with blades. Order clamps separately.
clamp
435154
435155
435194
435156
435157
E124
