Separator™
Toolholders
Right Hand Tool
Universal Style Toolholder • 76mm Bar Capacity
order number
right hand
3538739
3615306
catalogue number
206411
206443
NOTE: Support blade requires two screws.
Order blades separately.
B
27,00
27,00
H
25,00
32,00
H2
56,36
56,36
F
39,78
39,78
L1
102,96
102,96
L
150,85
150,85
support blade
screw
MS1072
MS1072
clamp
screw
MS352
MS1294
Components
W L1
3.0 57,05
4.0 57,05
NOTE: All components ship separately.
FS
1,27
1,84
left hand clamp
435137
435106
support blade
309111
309105
right hand clamp
435136
435103
L1 Blade
L1 Assy
L1 Holder
F Holder
F Assy
W FS Blade
L1 Assy = L1 (holder) + L1 (blade)
F Assy = F (holder) + FS (blade) + W/2
