WIDIA - Полный каталог инструмента - 2017
Separator™
Toolholders
для размещения заказа - zakaz@widiahanita.ru
Left Hand Tool
Universal Style Toolholder • 56mm Bar Capacity
Right Hand Tool
order number
right hand
3614289
catalogue number
206408
NOTE: Support blade requires two screws.
Order blades separately.
Components
B
26,97
H
25,00
H2
43,66
F
40,16
L1
105,46
L
144,14
clamp
screw
MS1294
W L1 FS
2.5 44,50 0,91
3.0 44,50 1,27
4.0 44,50 1,84
NOTE: All components ship separately.
left hand clamp
for 206410
435149
435104
435105
left hand clamp
for 206442
435151
435110
435109
support
blade
310109
310102
310108
right hand clamp
for 206441
435150
435116
435117
right hand clamp
for 206408
435148
435101
435102
L1 Blade
F Holder
F Assy
L1 Assy
L1 Holder
W FS Blade
L1 Assy = L1 (holder) + L1 (blade)
F Assy = F (holder) + FS (blade) + W/2
E126
