TopThread
Holder Identication System
TopThread™
Catalogue Numbering System
N
Insert
Holding
Method
N—
TopThread™
S
Insert
Mounting
Location
End mount
E
Side mount,
offset
S
Side mount,
no offset
AS
R
Hand
of Tool
Drop
Head
2525
Shank
Size
NSR2525M4
M
Tool
Length
4
Insert
Size
Qualied
Holder
Shank height and
width in mm and
holder
DH
L1 ISO
32 A
40 B
50 C
60 D
70 E
80 F
90 G
100 H
110 J
125 K
140 L
150 M
160 N
170 P
180 Q
200 R
250 S
300 T
350 U
400 V
450 W
500 Y
special x
length
Q — Qualified
W1 holder
insert
size W1
2 3,81
3 4,95
4 6,98
5 9,65
6 9,73
8 11,13
End mount
RL
Side mount
RL
