TopThread™
Catalogue Numbering System
для размещения заказа - zakaz@widiahanita.ru
TopThread
Boring Bar Identication System
A25RNNT0R2
A 25 R N N T O R 2
Bar
Bar
Bar Insert
Insert
Insert
Rake Hand of Tool Insert
Type
Diameter Length
Holding
Shape
Location
Angle
Size
Method
0 = 0°
Steel
with coolant
A
N—
TopThread*
End mount
E
Right hand
R
W1
Bar in millimetres
DDiiaa..
Bars
K = 125,0mm
M = 150,0mm
Q = 180,0mm
R = 200,0mm
S = 250,0mm
T = 300,0mm
U = 350,0mm
*Proprietary
standard only.
Side mount
S
Left hand
L
insert
size W1
2 3,81
3 4,95
4 6,98
5 9,65
6 9,73
8 11,13
F30
