TopThread™
Boring Bars
Steel shank with
through coolant.
See page F8
for inserts.
A-NNT
Right Hand Tool
D min
seat
order number catalogue number size D D min L1
F
gage
clamp clamp
hex/
CS
insert clamp
screw
screw Torx Plus
right hand
3641643
A16MNNTOR2
2 16 22,0 150 11 1/8-27 NPT N.2L
CM75 MS1200
—
2.5 mm
3641645
A20QNNTOR2
2 20 26,0 180 13 1/8-27 NPT N.2L
CM75 MS1200
—
2.5 mm
3641651
A25RNNTOR2
2 25 34,0 200 17 1/4-18 NPT N.2L
CM75 MS1200
—
2.5 mm
3641622
A25RNNTOR3
3 25 34,0 200 17 1/8 - 27 NPT N.3L CM73LP
—
MS2111
25 IP
3641646
A32SNNTOR3
3 32 44,0 250 22 1/4-18 NPT N.3L CM73LP
—
MS2111
25 IP
3641653
A40TNNTOR3
3 40 54,0 300 27 1/4-18 NPT N.3L CM73LP
—
MS2111
25 IP
3641654
A40TNNTOR4
4 40 54,0 300 27 1/4-18 NPT N.4L CM73LP
—
MS2111
25 IP
3641661
A50UNNTOR4
4 50 70,0 350 35 1/4-18 NPT N.4L CM73LP
—
MS2111
25 IP
3641644
A12MNNTOR2
2 12 18,5 150 11 1/16-27 NPT NG2L CM147 MS1200
—
2.5 mm
left hand
3641649
A16MNNTOL2
2 16 22,0 150 11 1/8-27 NPT N.2R CM74 MS1200
—
2.5 mm
3641652
A20QNNTOL2
2 20 26,0 180 13 1/8-27 NPT N.2R CM74 MS1200
—
2.5 mm
3641657
A25RNNTOL2
2 25 34,0 200 17 1/4-18 NPT N.2R CM74 MS1200
—
2.5 mm
3641650
A25RNNTOL3
3 25 34,0 200 17 1/4-18 NPT N.3R CM72LP
—
MS2111
25 IP
3641656
A32SNNTOL3
3 32 44,0 250 22 1/4-18 NPT N.3R CM72LP
—
MS2111
25 IP
3641659
A40TNNTOL3
3 40 54,0 300 27 1/4-18 NPT N.3R CM72LP
—
MS2111
25 IP
3641663
A40TNNTOL4
4 40 54,0 300 27 1/4-18 NPT N.4R CM72LP
—
MS2111
25 IP
3641690
A50UNNTOL4
4 50 70,0 350 35 1/4-18 NPT N.4R CM72LP
—
MS2111
25 IP
3641655
A12MNNTOL2
2 12 18,5 150 11 1/16-27 NPT NG2R CM146 MS1200
—
2.5 mm
NOTE: F dimension measured over sharp point of insert.
