Laydown Threading
KM™ Units
для размещения заказа - zakaz@widiahanita.ru
LSS 90°
L1 F
order number
catalogue number
L1
mm in
F
mm in
gage
insert
insert
screw
shim
shim
clamp
screw assembly kg lbs
right hand
3950857
KM40TSLSSR16
40 1.575 27 1.063 LT16ER
SSA3T SMYE3 SSY3T
CKC3
0,31 .68
3950858
3959401
KM40TSLSSR22
KM40TSLSSR27
40 1.575 27 1.063
45 1.772 27 1.06
LT22ER
LT27ER
SSA4T
SSA5T
SMYE4
SMYE5
SSY4T
SSY5T
CKC4
CKC5
0,30 .66
0,37 .82
left hand
3950855
3950856
KM40TSLSSL16
KM40TSLSSL22
40 1.575 27 1.063
40 1.575 27 1.063
LT16EL
LT22EL
SSA3T
SSA4T
SMYI3
SMYI4
SSY3T
SSY4T
CKC3
CKC4
0,32 .70
0,31 .68
3959400
KM40TSLSSL27
45 1.772 27 1.063 LT27EL
SSA5T
SMYI5 SSY5T
CKC5
0,37 .82
NOTE: Cutting units are supplied with insert screw and clamp assembly. However, tools are designed to use either the insert screw or the clamp assembly, not both.
