WIDIA - Полный каталог инструмента - 2017
Laydown Threading
Boring Bars
для размещения заказа - zakaz@widiahanita.ru
Steel shank
without through
coolant.
See page F42
for inserts.
N/A-VR
Right Hand Tool
order number catalogue number insert size D D min D2 F L1 L2 aF° aP°
right hand
2025828
NVR102R
2 20 13 10 7 180 25 -15,0° -1,5
2022342
NVR132R
2 20 16 13 9 180 32 -15,0° -1,5
2012307
NVR163R
3 20 20 16 12 180 40 -15,0° -1,5
2009609
AVR203R
3 20 24 20 13 180 50 -15,0° -1,5
2022343
NVR204R
4 20 27 20 16 180 50 -15,0° -1,5
2009628
AVR25D3R
3 25 29 25 16 200 45 -15,0° -1,5
2009631
AVR25D4R
4 25 32 25 17 200 45 -15,0° -1,5
2009612
AVR253R
3 32 29 25 16 250 60 -15,0° -1,5
2009625
AVR254R
4 32 32 25 17 250 60 -15,0° -1,5
2009640
AVR32D3R
3 32 36 32 20 250 60 -15,0° -1,5
2009634
AVR324R
4 32 39 32 22 250 60 -15,0° -1,5
2009637
AVR325R
5 32 40 32 22 250 60 -15,0° -1,5
2009643
AVR403R
3 40 44 40 24 300 60 -15,0° -1,5
2009646
AVR405R
5 40 48 40 26 300 60 -15,0° -1,5
2009649
AVR505R
5 50 58 50 31 350 75 -15,0° -1,5
left hand
2071317
NVR163L
3 20 20 16 12 180 40 -15,0° -1,5
2071318
AVR203L
3 20 24 20 13 180 40 -15,0° -1,5
2065134
AVR25D3L
3 25 29 25 16 200 45 -15,0° -1,5
2065135
AVR25D4L
4 25 32 25 17 200 45 -15,0° -1,5
2114832
AVR253L
3 32 29 25 16 250 60 -15,0° -1,5
NOTE: Items listed without a shim are designed for a 1,5° inclination angle.
shim
—
—
SMYI3
SMYI3
SMYI4
SMYI3
SMYI4
SMYI3
SMYI4
SMYI3
SMYI4
SMYI5
SMYI3
SMYI5
SMYI5
SMYE3
SMYE3
SMYE3
SMYE4
SMYE3
shim
insert
screw Torx screw Torx
—
—
SSY3T
SSY3T
SSY4T
SSY3T
SSY4T
SSY3T
SSY4T
SSY3T
SSY4T
SSY5T
SSY3T
SSY5T
SSY5T
— SSN2T T8
— SSN2T T8
T10 SSA3T T10
T10 SSA3T T10
T20 SSA4T T20
T10 SSA3T T10
T20 SSA4T T20
T10 SSA3T T10
T20 SSA4T T20
T10 SSA3T T10
T20 SSA4T T20
T25 SSA5T T25
T10 SSA3T T10
T25 SSA5T T25
T25 SSA5T T25
SSY3T
SSY3T
SSY3T
SSY4T
SSY3T
— SSA3T T10
T10 SSA3T T10
T10 SSA3T T10
T20 SSA4T T20
T10 SSA3T T10
