Laydown Threading
Boring Bars
See page F42
for inserts.
OVR
order number catalogue number
insert
size
D D min D2 F L1 L2 aF° aP°
screw
Torx
driver
Torx
right hand
2012325
OVR122R
2 12 13 10 7 100 25 -15,0° -0,5 12147789100 12148001100 T8
2022345
OVR152R
2 15 16 13 9 100 32 -15,0° -0,5 12147789100 12148001100 T8
NOTE: WIDIA™ miniature holders are for use on automatic machines as used in the optical and precision mechanics industries. The shank dimensions correspond to
conventional hardmetal or HSS tools. Holders with round or square shanks are available. An internal RH tool can also be used for external LH threads in the same
way an internal LH tool can be used for external RH threads. Please use correct inserts. The inclination angle on this tool is 0,5°. Tools are always clamped with
the shank parallel to the part.
