Face Mills • Victory™ M1200 Series
Victory M1200 HF • Shell Mills
• Twelve cutting edges.
• High feed rates for rough face milling.
• Use standard M1200 inserts.
• Do not load wiper inserts.
Shell Mills
order number
catalogue number
coolant
D1 D1 max D
D6
L Ap1 max Z max RPM supply
kg
3750370
M1200HF050Z04HN09
50
67,9 22 38 40
2,2
4 11400
Yes 0,65
3750372
M1200HF063Z05HN09
63
80,9 22 50 40
2,2
5 8950
Yes 0,65
3750434
M1200HF080Z06HN09
80
97,9 27 60 50
2,2
6 7300
Yes 1,24
3750435
M1200HF100Z08HN09 100
117,9
32 80 50
2,2
8 5900
Yes 1,89
3750436
M1200HF125Z09HN09 125
142,9
40 90 63
2,2
9 4800
Yes 3,23
3957969
M1200HF160Z12HN09 160
177,9
40 110 63
2,2
12 3900
Yes 5,14
Spare Parts
insert
Torx
socket-head socket-head cap screw
coolant lock
coolant
D1 screw
Nm
driver
cap screw
with coolant groove
screw assembly lock screw
50 12146034500 3,5 12148082400 12146120500
12146101000
—
—
63 12146034500 3,5 12148082400 12146120500
12146101000
—
—
80 12146034500 3,5 12148082400 12748701000
12146101800
—
—
12146034500 3,5 12148082400
—
—
12146109400
—
125 12146034500 3,5 12148082400
—
—
— 12146107000
160 12146034500 3,5 12148082400
—
—
— 12146107000
NOTE: Socket-head cap screw with coolant groove, coolant lock screw assembly, coolant lock screw, and coolant cap must be ordered separately.
coolant
cap
—
—
—
—
12146111000
12146111100
H26
