Face Mills • M4000 Series
Tool Bodies • Cartridge Milling System
Cartridge
order number
4159022
catalogue number
M4000CA-AD1505
insert
style
AD.T1505
4159020
M4000CA-AP1003
AP.T1003
4159021
M4000CA-AP1604
AP.T1604
3968124
M4000CA-HN07
HN.J0704/XNGJ0704
4159018
M4000CA-HN07HD
HN.J0704
4159017
M4000CA-HN07HF
HN.J0704
3126691
M4000CA-HN09
HN.J0905/XNGJ0905
4159019
M4000CA-HN09HD
HN.J0905
3954792
M4000CA-HN09HF
HN.J0905
2511344
M4000CA-HP06
HP.T06T3
2006361
M4000CA-MDHX10
MDHX1004
2006346
M4000CA-RC1606
RC.T1606
2067492
M4000CA-SD1204
SDM.1204
2006359
M4000CA-SD1506
SDM.1506
2006374
M4000CA-SE1203
SE.N1203/SE.R1203
2033495
M4000CA-SE1204
SE.N1204/SE.R1204
2006377
M4000CA-SE1504
SE.N1504/SE.R1504
2006348
M4000CA-SN12
SN.T1205/XNKT1205
2006360
M4000CA-SN15
SN.T1505
2006362
M4000CA-SP12
121358680
2006373
M4000CA-SP1203
SP.N1203/SP.R1203
2006376
M4000CA-SP1504
SP.N1504
2033496
M4000CA-TP1603
TP.N1603/TP.R1603
2006379
M4000CA-TP2204
TP.N2204/TP.R2204
2006347
M4000CA-XP16
XP.T1604
* For all details regarding insert offering and cutting conditions, please refer to the master platforms.
master
platform *
CIP
CIP
CIP
M1200 Mini
M1200 Mini
M1200 Mini
M1200
M1200
M1200
M640
M76
M100
M690
M690
M68
M68
M68
M660
M660
M40Wiper
M40
M40
M40
M40
M680
Ap max
14,0
10,2
16,2
3,5
4,7
1,0
4,4
6,0
2,2
4,8
1,0
8,0
11,7
14,9
6,0
6,0
8,0
6,4
8,0
9,0
9,0
12,0
12,0
18,0
14,0
