Victory™ Shoulder Mills • VSM11™ Series
Shell Mills
• True 90° capability.
• Increased ramping capability.
• Superior wall and surface finish.
• Effective internal coolant feature,
precisely reaching the cutting edge.
Shell Mills
order number
catalogue number
max coolant
D1 D D6 L Ap1 max Z ramp angle supply max RPM kg
5416316
VSM11D040Z04S016XD11
40 16 37 40
11,4
4
2.6°
Yes
22600
0,22
5416317
VSM11D040Z06S016XD11
40 16 37 40
11,4
6
2.6°
Yes
22600
0,22
5416318
VSM11D050Z05S022XD11
50 22 44 40
11,3
5
1.9°
Yes
19900
0,33
5416319
VSM11D050Z08S022XD11
50 22 44 40
11,3
8
1.9°
Yes
19900
0,33
5416340
VSM11D063Z06S022XD11
63 22 44 40
11,3
6
1.5°
Yes
17500
0,50
5416341
VSM11D063Z09S022XD11
63 22 44 40
11,3
9
1.5°
Yes
17500
0,52
5416342
VSM11D080Z08S027XD11
80 27 60 50
11,3
8
1.1°
Yes
15300
1,14
5416345
VSM11D100Z09S032XD11 100 32 80 50
11,3
9
0.9°
Yes
13600
1,79
5416347
VSM11D125Z011S040XD11 125 40 80 63
11,3
11
0.7°
Yes
12100
3,01
Spare Parts
insert
D1 screw
40,0 192.432
Nm
1,0
wrench
170.028
socket-head
cap screw
MS1294
50,0 192.432
1,0
170.028
12146120500
63,0 192.432
1,0
170.028
12146120500
80,0 192.432
1,0
170.028
125.230
100,0
192.432
1,0
170.028
–
125,0
192.432
1,0
170.028
–
NOTE: Socket-head cap screw and coolant lock screw assembly must be ordered separately.
socket-head cap screw
with coolant groove
MS1294CG
MS1234CG
MS1234CG
MS2038CG
–
–
coolant lock
screw assembly
–
–
–
–
MS2195C
MS2187C
J8
