Victory™ Shoulder Mills • VSM17™ Series
Screw-On End Mills
Screw-On End Mills
order number
catalogue number
D1 D DPM G3X L2 WF Ap1 max Z
5988091 VSM17D025Z02M12XD17 25 21 12,5 M12 35 17 16,3 2
5988092 VSM17D032Z03M16XD17 32 29 17,0 M16 40 24 16,3 3
5988132 VSM17D32Z02M016XD17 32 29 17,0 M16 40 24 16,3 2
5988093 VSM17D040Z04M16XD17 40 29 17,0 M16 40 24 16,2 4
5988131 VSM17D40Z03M016XD17 40 29 17,0 M16 40 24 16,2 3
Spare Parts
max
ramp
angle
8.8
5.7
5.7
4.0
4.0
coolant
supply
Yes
Yes
Yes
Yes
Yes
max RPM
41800
34700
34700
29800
29800
kg
0,08
0,17
0,18
0,20
0,20
insert
screw
Nm
191.725
3,5
NOTE: Standard milling cutters will accept insert nose radii up to 1,6mm without modication.
For tool body modication instructions, see page J16.
wrench
170.025
J20
