Slotting Mills • M94 Series
Weldon® Shanks
• Three cutting edges per insert.
• Tangential mounted inserts.
• Shallow grooving and slotting.
для размещения заказа - zakaz@widiahanita.ru
Weldon Shanks
order number catalogue number D1 D D3 D min L L2 W min W max Z
insert 1
coolant
supply kg
2022619
12290900800
25 25 21 34 100 44 1,93 2,73 3 TCAX1103ZZ.. No 0,4
2022620
12290901200
40 32 32 65 110 50 2,73 4,26 3 TNAX1604ZZ.. No 0,7
NOTE: D min = minimum internal hole diameter required for clearance.
Spare Parts
insert
Torx
D1 screw Nm driver
25 12148080000 1,0 12148086600
40 12148067200 3,5 12148086600
L10
