Slotting Mills • M900™ Series
Inserts
для размещения заказа - zakaz@widiahanita.ru
Insert Selection Guide
Material
Group
P1–P2
P3–P4
P5–P6
M1–M2
M3
K1–K2
K3
N1–N2
N3
S1–S2
S3
S4
H1
Light
Machining
Geometry
Grade
MDHX
WP40PM
MDHX
WP35CM
MDHX
WP35CM
MDHX
WP25PM
MDHX
WP35CM
MDHX
WK15CM
MDHX
WK15CM
––
––
MDHX
WP25PM
MDHX
WU35PM
MDHX
WP25PM
––
Inserts • MDH..
General
Purpose
Geometry
Grade
MDHX
WP40PM
MDHX
WP35CM
MDHX
WP40PM
MDHX
WP25PM
MDHX
WP40PM
MDHX
WK15CM
MDHX
WP35CM
––
––
MDHX
WU35PM
MDHX
WU35PM
MDHX
WU35PM
––
Heavy
Machining
Geometry
Grade
MDHX
WP40PM
MDHX
WP35CM
MDHX
WU35PM
MDHX
WU35PM
MDHX
WU35PM
MDHX
WK15CM
MDHX
WP35CM
––
––
MDHX
WU35PM
MDHX
WU35PM
MDHX
WU35PM
––
MDHX
MDHX
MDHX
first choice
alternate choice
P
M
K
N
S
H
catalogue number
MDHX09T308
cutting
edges
2
D
D1 L10
M
S
R
9,53 3,40 9,55 1,85 3,97 0,80
Recommended Starting Feeds
Recommended Starting Feeds [mm]
Light
Machining
General
Purpose
Heavy
Machining
Insert
Geometry
5%
Programmed Feed per Tooth (fz)
as a % of Radial Depth of Cut (ae)
10% 20% 30%
40–100%
MDHX
0,12 0,23 0,46 0,08 0,17 0,33 0,06 0,13 0,25 0,06 0,11 0,22 0,05 0,10 0,20
NOTE: Use “Light Machining” value as starting feed rate.
