Copy Mills • M370™ Series
iC08 • Shell Mills
для размещения заказа - zakaz@widiahanita.ru
• Double-sided, six cutting edges.
• Highest metal removal rates.
• First choice for roughing applications.
D6
D
L
Shell Mills
D1
D1 max
Ap1 max
order number
catalogue number
coolant
D1 max D1 D D6 L Ap1 max Z max RPM supply
kg
4056193 M370D040Z04WO08 40 26 16 37 40 1,3 4 33500
Yes 0,19
4170922 M370D040Z05WO08 40 26 16 37 40 1,3 5 33500
Yes 0,19
4008276 M370D050Z05WO08 50 36 22 44 40 1,3 5 29200
Yes 0,29
4171223 M370D050Z06WO08 50 36 22 44 40 1,3 6 29200
Yes 0,29
4171224 M370D052Z06WO08 52 38 22 44 50 1,3 6 28600
Yes 0,40
4056194 M370D052Z05WO08 52 38 22 44 50 1,3 5 28600
Yes 0,41
4056195 M370D063Z06WO08 63 49 22 60 50 1,3 6 25500
Yes 0,74
4008277 M370D066Z06WO08 66 52 27 60 50 1,3 6 24900
Yes 0,77
4171225 M370D080Z07WO08 80 66 27 60 50 1,3 7 24900
Yes 2,36
Spare Parts
D1 max
insert
screw
Torx Plus
Nm driver
40 MS2219 1,8
DT9IP
50 MS2219 1,8
DT9IP
52 MS2219 1,8
DT9IP
63 MS2219 1,8
DT9IP
66 MS2219 1,8
DT9IP
80 MS2219 1,8
DT9IP
NOTE: Socket-head cap screw with coolant groove must be ordered separately.
socket-head
cap screw
125.825
12146120500
12146120500
12146120500
MS2038
MS2038
socket-head cap screw
with coolant groove
MS1294CG
MS1234CG
MS1234CG
MS1234CG
MS2038CG
MS2038CG
M6
