Copy Mills • M370™ Series
iC12 • Shell Mills
для размещения заказа - zakaz@widiahanita.ru
• Double-sided, six cutting edges.
• Highest metal removal rates.
• First choice for roughing applications.
Shell Mills
order number
catalogue number
D1 max
D1
coolant
D D6 L Ap1 max Z max RPM supply
kg
5338913 M370D50Z04WO12 50,0 33 22 42 50 2,0 4 19530
Yes 0,38
5338914
M370D52Z04WO12
52,0 35 22 49 50
2,0
4 19160
Yes 0,47
5338915
M370D63Z04WO12 63,0 46 22 49 50
2,0
4 17400
Yes 0,57
5338916
M370D63Z05WO12 63,0 46 22 49 50
2,0
5 17400
Yes 0,57
5338917
M370D66Z05WO12 66,0 49 27 60 50
2,0
5 17000
Yes 079
5338918
M370D80Z05WO12 80,0 63 27 60 50
2,0
5 15440
Yes 0,94
5338919
M370D80Z06WO12 80,0 63 27 60 50
2,0
6 15440
Yes 0,94
5338920
M370D100Z06WO12
100,0
83 32 78 50
2,0
6 13810
Yes 1,56
5338921
M370D100Z07WO12
100,0
83 32 78 50
2,0
7 13810
Yes 1,57
5338922
M370D125Z07WO12
125,0
108 40 90 63
2,0
7 12350
Yes 2,92
5338923
M370D125Z09WO12
125,0
108 40 90 63
2,0
9 12350
Yes 2,94
Spare Parts
D1 max
insert
screw
Torx Plus
socket-head
socket-head cap screw
Nm
driver
cap screw
with coolant groove
50 MS2085
4,0
DT15IP
12146120500
MS1234CG
52 MS2085
4,0
DT15IP
12146120500
MS1234CG
63 MS2085
4,0
DT15IP
125.025
MS1234CG
66 MS2085
4,0
DT15IP
125.230
MS2038CG
80 MS2085
4,0
DT15IP
125.230
MS2038CG
100 MS2085
4,0
DT15IP
—
—
125 MS2085
4,0
DT15IP
—
—
NOTE: Socket-head cap screw with coolant groove and coolant lock screw assembly must be ordered separately.
coolant
lock screw
—
—
—
—
—
KLS32M
KLS40M
coolant lock
screw assembly
—
—
—
—
—
MS2195C
MS2187C
M12
