• Double-sided, eight cutting edges.
• Anti-rotation feature for better stability
and higher feed rates.
• Pocketing and profiling capabilities.
Copy Mills • M200™ Series
iC10 • Shell Mills
Shell Mills
coolant
order number
catalogue number
D1 max
D1
D
D6
L
Ap1 max Z max RPM
supply
kg
5210305 M200D40Z04RN10 40 30 16 38 40 5,0 4 43200
Yes 0,23
5210306 M200D40Z06RN10 40 30 16 38 40 5,0 6 43200
Yes 0,24
5210307 M200D50Z05RN10 50 40 22 42 40 5,0 5 38600
Yes 0,32
5210308 M200D50Z06RN10 50 40 22 42 40 5,0 6 38600
Yes 0,32
5210309 M200D52Z06RN10 52 42 22 49 50 5,0 6 37900
Yes 0,52
Spare Parts
D1 max
40
insert
screw
191.848
Nm
2,0
wrench
170.025
socket-head
cap screw
MS1294
50 191.848
2,0
170.025
MS1234
52 191.848
2,0
170.025
MS1242
NOTE: Socket-head cap screw and socket-head cap screw with coolant groove must be ordered separately.
socket-head cap screw
with coolant groove
MS1294CG
MS1234CG
MS1242CG
