Copy Mills • M170™ Series
Additional Application Advice • RD1003..
Selecting the Correct Cutting Values
1. fz depends on the Ap1 and ae values
With round inserts, two factors can affect the hm: Ap1 and ae.
fz has to be adjusted accordingly.
Recommended Starting Feed Rate Values (fz) Related to the Ap1 and ae Values:
ae engagement
Ap1 = 0,5mm
Ap1 = 0,75mm
Ap1 = 1mm
Ap1 = 2mm
Ap1 = 3mm
Ap1 = 5mm
10%
1,18mm
0,95mm
0,80mm
0,57mm
0,46mm
0,36mm
20%
0,70mm
0,62mm
0,57mm
0,40mm
0,33mm
0,25mm
30%
0,63mm
0,56mm
0,46mm
0,33mm
0,27mm
0,21mm
40%
0,56mm
0,50mm
0,40mm
0,28mm
0,23mm
0,18mm
50%
0,50mm
0,45mm
0,36mm
0,25mm
0,21mm
0,16mm
100%
0,35mm
0,30mm
0,25mm
0,18mm
0,15mm
0,11mm
Example application
highlighted.
Example Cutting Conditions for RD..10... Insert in Pocketing, L/D ratio = 2 x D:
TN2505
TN6525
TN6540
feed per tooth fz (mm)/ae>50%
insert = RDPX1003M0SN
min med max min med max min med max
Edge Geometry MM ae>50% Recommended starting Ap1 = 1mm
–
–
– 0,25mm 0,30mm 0,40mm 0,25mm 0,32mm 0,45mm
Edge Geometry MH ae>50% Recommended starting Ap1 = 1mm 0,25mm 0,32mm 0,40mm 0,25mm 0,35mm 0,55mm 0,25mm 0,45mm 0,65mm
2. Ap1 and vc corrections depend on L/D ratio
With increasing L/D ratios, or overhang, vibrations can occur due to reduced
rigidity. To ensure successful application, it is recommended to adjust Ap1
and vc values according to the following table:
L/D ratio
<2
2<L/D<4
>4
% of Ap1 max
to reduce
0%
65–75%
80–95%
% of vc
to reduce
0%
10–15%
20–40%
L
L
D
Recommended Cutting Conditions • Helical Interpolation from Solid
cutter diameter
20
22
25
28
30
35
40
42
50
52
min hole
diameter
22mm
24mm
33mm
36mm
40,6mm
50,7mm
60,5mm
64,5mm
80,3mm
85,8mm
max hole diameter
(at bottom)
30mm
34mm
40mm
46mm
50mm
60mm
70mm
74mm
90mm
94mm
Ap1 max per
revolution
2,1mm
2,1mm
3,2mm
5mm
5mm
5mm
5mm
5mm
5mm
5mm
max ramp
angle
20°
20°
8°
15°
10°
8,5°
7,2°
5,8°
5,2°
3°
Ap1 max
when plunging
4mm
2,4mm
1,7mm
3,8mm
3,4mm
3,4mm
3,6mm
3,6mm
4mm
2,2mm
L
D
D
Cutter
Diameter
Hole
Diameter
M58
