• Premium nickel-coated bodies.
• Designed for maximum performance.
• Ideally suited for die and mould manufacturing.
Copy Mills • M170™ Series
Screw-On End Mills • RD12T3..
Screw-On End Mills
order number
catalogue number
max
ramp
coolant
D1 max D1 D DPM G3X L2 WF Ap1 max Z angle max RPM supply kg
3930950 M170D024Z02M12RD12 24 12 21 12,5 M12 35 19 6,0 2 15.0° 13200
Yes 0,08
3930954 M170D035Z03M16RD12 35 23 29 17,0 M16 43 22
6,0
3 11.0°
9900
Yes 0,22
3930956 M170D035Z04M16RD12 35 23 29 17,0 M16 43 22
6,0
4 10.5°
9900
Yes 0,21
3930958 M170D042Z05M16RD12 42 30 29 17,0 M16 43 22 6,0 5 7.2° 7500
Yes 0,26
Spare Parts
D1 max
insert
screw
24 193.342
35 193.342
42 193.342
NOTE: All spare parts except the insert screws must be ordered separately.
Nm
3,5
3,5
3,5
clamp
screw
193.338
193.338
193.338
Torx
driver
12148082400
12148082400
12148082400
