• Premium nickel-coated bodies.
• Designed for maximum performance.
• Ideally suited for die and mould manufacturing.
Copy Mills • M170™ Series
Shell Mills • RD1604..
Shell Mills
max
ramp
coolant
order number catalogue number D1 max D1 D D6 L Ap1 max Z angle max RPM supply
kg
3926602
M170D050Z04RD16
50
34 22 44 40
8,0
4 8.5°
7900
Yes 0,28
3934623
M170D052Z04RD16
52
36 22 44 50
8,0
4 8.2°
7650
Yes 0,36
3934624
M170D063Z05RD16
63
47 22 44 40
8,0
5 5.5°
5300
Yes 0,39
3934625
M170D066Z05RD16
66
50 27 60 50
8,0
5 4.0°
6000
Yes 0,74
3934626 M170D080Z06RD16 80 64 27 60 50 8,0 6 3.0° 4900
Yes 1,06
3934628
M170D100Z07RD16
100
84 32 80 55
8,0
7 2.4°
3950
Yes 1,94
3934629 M170D125Z08RD16 125 109 40 90 60 8,0 8 2.2° 3200
Yes 2,90
Spare Parts
insert
clamp
D1 max screw Nm screw
Torx
driver
low-head
cap screw
low-head cap screw
with coolant groove
50 193.343 6,0 193.383 12148099400
129.025
—
52 193.343 6,0 193.383 12148099400
129.025
—
63 193.343 6,0 193.383 12148099400
129.025
—
66 193.343 6,0 193.383 12148099400
—
—
80 193.343 6,0 193.383 12148099400
—
—
100 193.343 6,0 193.383 12148099400
MS1254
MS1254CG
125 193.343 6,0 193.383 12148099400
129.512
—
NOTE: All spare parts except the insert screws and clamp screws must be ordered separately.
socket-head
cap screw
—
—
—
MS2038
MS2038
—
—
socket-head cap screw coolant coolant
with coolant groove lock screw cap
MS2072CG
——
MS2072CG
——
MS2072CG
——
MS2038CG
——
MS2038CG
——
— ——
— 420.200 470.232
