WIDIA - Полный каталог инструмента - 2017
Copy Mills • M100™ Series
Shell Mills • RC1606..
для размещения заказа - zakaz@widiahanita.ru
• General purpose face and copy milling.
• Anti-rotation feature for top security.
Shell Mills
max
ramp
coolant
order number catalogue number D1 max D1 D D4 D6 L Ap1 max Z angle max RPM supply kg
2021358
12391023400
50
34 22 — 40 40
8,0
4 6.0°
13000
Yes 0,20
2021359
12391023600
52
36 22 — 40 40
8,0
4 5.8°
13000
Yes 0,30
2021357
12391023200
63
47 27 — 48 40
8,0
5 4.0°
12000
Yes 0,20
2021360
12391023800
66
50 27 — 48 40
8,0
5 3.8°
12000
Yes 0,30
2021352
12391022000
80
64 27 — 60 50
8,0
6 2.8°
10000
Yes 0,90
2021353
12391022200
100 84 32 — 78 50 8,0
7 2.3°
9000
No 1,20
2021354
12391022400
125 109 40 — 89 50
8,0
8 1.8°
8000
No 1,80
2021355
12391022600
160 144 40 67 90 63
8,0
9 1.3°
7000
No 2,90
2021356
12391022800
200 184 60 102 130 63 8,0 11 0.8° 6000
No 0,30
Spare Parts
D1 max
insert
screw
Nm
50 12148007200
4,0
52 12148007200
4,0
63 12148007200
4,0
66 12148007200
4,0
80 12148007200
4,0
100 12148007200
4,0
125 12148007200
4,0
160 12148007200
4,0
200 12148007200
4,0
NOTE: All spare parts except the insert screws must be ordered separately.
Torx
driver
12148007500
12148007500
12148007500
12148007500
12148007500
12148007500
12148007500
12148007500
12148007500
socket-head
cap screw
125.025
125.025
125.230
125.230
125.230
—
—
—
—
socket-head cap screw
with coolant groove
MS1234CG
MS1234CG
MS2038CG
MS2038CG
MS2038CG
—
—
—
—
M96
