Copy Mills • M270™ Series

High-Feed Tool Bodies

для размещения заказа - zakaz@widiahanita.ru

• High metal removal rates.

• Excellent in long reach applications.

• Rough and semi-finishing applications.

High-Feed • Screw-On End Mills

order number catalogue number D1 D DPM G3X L L2 WF Ap1 max Z Z U

3926546

M270TD012M08 12 13 8,5 M8 42 25 10 0,6 1 2

3926547

M270TD016M08 16 13 8,5 M8 47 30 10 0,9 1 2

3926548

M270TD020M10 20 18 10,5 M10 59 40 14 1,1 1 2

NOTE: ZU = Effective teeth.

Z = number of pocket seats.

*D1 = 13mm when using M270HF13; D1 = 17mm when using M270HF17.

insert 1

M270HF12

M270HF16

M270HF20

insert 2*

M270HF13

M270HF17

—

coolant

max RPM supply kg

55000

Yes 0,02

53000

Yes 0,09

52000

Yes 0,07

Spare Parts

insert

D1 screw
