High-Performance Solid Carbide End Mills • VariMill™
Series 47N6 • VariMill I™ • Extended Reach with Neck
• Unequal flute spacing.
• Centre cutting.
• Single tool for both roughing and finishing
operations requiring fewer setups.
• Standard items listed. Additional styles
and coatings made-to-order.
Detail X
Series 47N6 • VariMill • Extended Reach with Neck
D1
)3
> 3-6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance e8
-0,014/-0,028
-0,020/-0,038
-0,025/-0,047
-0,032/-0,059
-0,040/-0,073
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
graTdieATlNiA-LlNW-LW
TiAlN
order #
4067705
4067706
4067707
4067708
4067709
4067710
catalogue #
47N606002LW
47N608003LW
47N610004LW
47N612005LW
47N616006LW
47N620007LW
D1
6,0
8,0
10,0
12,0
16,0
20,0
first choice
alternate choice
length of cut
length
D D3 Ap1 max L3 L BCH
6 5,50
12,00
42,00
100
0,40
8 7,30
16,00
62,00
100
0,40
10 9,10
20,00
60,00
100
0,50
12 11,00
24,00
73,00
125
0,50
16 14,56
32,00
100,00
150
0,50
20 18,20
40,00
98,00
175
0,50
