High-Performance Solid Carbide End Mills • Roughing
Series 422150 422152
• Centre cutting.
• Cord profile.
• Standard items listed. Additional
styles and coatings made-to-order.
Detail X
Series 422150 422152
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h10
+/-
D
0/-0,040
)3
0/-0,048
> 3–6
0/-0,058
> 6–10
0/-0,070
> 10–18
0/-0,084
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choice
graKde30KF3-0DFC-HDPCHP
TiAlN
order # catalogue #
graKde30KF3-0DFC-HDPCHP
TiAlN
order # catalogue #
length of cut
length
D1 D
Ap1 max
L BCH
2630665 422150-000060
2630679 422152-000060
6,0
6
13,00
57 0,10
2630667 422150-000080
2630680 422152-000080
8,0
8
19,00
63 0,20
2630669 422150-000100 2630713 422152-000100 10,0 10
22,00
72 0,30
2630670 422150-000120 2630714 422152-000120 12,0 12
26,00
83 0,30
2630672 422150-000160 2630717 422152-000160 16,0 16
32,00
92 0,40
2630675 422150-000200 2630718 422152-000200 20,0 20
38,00
104 0,40
2630677 422150-000250 2630719 422152-000250 25,0 25
45,00
121 0,40
O56
