High-Performance Solid Carbide End Mills • Roughing
Series 4U40 • Victory™ Grades
• Centre cutting.
• Flat shallow pitch.
• Unequal flute spacing.
• Standard items listed. Additional
styles and coatings made-to-order.
Series 4U40 • Victory Grades
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance d11
-0,020/-0,080
-0,030/-0,105
-0,040/-0,130
-0,050/-0,160
-0,065/-0,195
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
first choice
alternate choice
graWdePW15PP1E5PE
AlTiN
order # catalogue #
5583159 4U4006002T
D1
6,0
length of cut
length
D Ap1 max
L
R
6 6,00
57 0,75
5583420 4U4008003T
8,0
8
8,00
63 0,75
5583421 4U4010004T
10,0
10
10,00
72 0,75
5583422 4U4012005T
12,0
12
12,00
83 1,00
5583423 4U4016006T
16,0
16
16,00
92 1,00
5583424 4U4020007T
20,0
20
20,00
104 1,25
5583425 4U4025008T
25,0
25
25,00
121 1,25
ZU
4
4
4
4
6
6
6
