High-Performance Solid Carbide End Mills • Roughing

Series 422820 422824

• Centre cutting.

• Flat shallow pitch.

• Standard items listed. Additional

styles and coatings made-to-order.

Detail X

Series 422820 422824

graKde30KF3-0DFC-HDPCHP

TiAlN

order # catalogue #

2628396 422820-000060

2628397 422820-000080

2628400 422820-000100

2628401 422820-000120

2628446 422820-000160

2628447 422820-000200

2628448 422820-000250

graKde30KF3-0DFC-HDPCHP

TiAlN

order # catalogue #

2628451 422824-000060

2628473 422824-000080

2628475 422824-000100

2628477 422824-000120

2628478 422824-000160

2628481 422824-000200

2628482 422824-000250

D1

6,0

8,0

10,0

12,0

16,0

20,0

25,0

D1

)3

> 3–6

> 6–10

> 10–18

> 18–30

End Mill Tolerances

tolerance h10

+/-

D

0/-0,040

)3

0/-0,048

> 3–6

0/-0,058

> 6–10

0/-0,070

> 10–18

0/-0,084

> 18–30

tolerance h6

+/-

0/-0,006

0/-0,008

0/-0,009

0/-0,011

0/-0,013

first choice

alternate choice

length of cut

length

D Ap1 max L

6

18,00

62

8

24,00

68

10 30,00 80

12 36,00 93

16

48,00

108

20

60,00

126

25

75,00

150

BCH
