High-Performance Solid Carbide End Mills • Roughing
Series 4U70 • Victory™ Grades
• Centre cutting.
• Flat shallow pitch.
• Unequal flute spacing.
• Standard items listed. Additional
styles and coatings made-to-order.
Detail X
Series 4U70 • Victory Grades
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance d11
-0,020/-0,080
-0,030/-0,105
-0,040/-0,130
-0,050/-0,160
-0,065/-0,195
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
graWdePW15PP1E5PE
AlTiN
order #
5583426
5583427
5583428
5583429
5583430
5583431
5583432
5583433
5583434
5583435
catalogue #
4U7006002T
4U7008003T
4U7010004T
4U7012005T
4U7016006T
4U7016046T
4U7020007T
4U7020047T
4U7025008T
4U7025048T
first choice
alternate choice
graWdePW15PP1E5PE
AlTiN
length of cut
length
order # catalogue # D1 D
Ap1 max
L BCH ZU
5583436 4U7006002W 6,0 6
13,00
57 0,30 4
5583437 4U7008003W 8,0 8
16,00
63 0,40 4
5583438 4U7010004W 10,0 10
22,00
72 0,50 4
5583439 4U7012005W 12,0 12
26,00
83 0,50 4
5583440 4U7016006W 16,0 16
32,00
92 0,60 6
—
16,0 16
32,00
92 0,60 4
5583441 4U7020007W 20,0 20
38,00
104 1,00 6
—
20,0 20
38,00
104 1,00 4
5583442 4U7025008W 25,0 25
45,00
121 1,12 6
—
25,0 25
45,00
121 1,12 4
