High-Performance Solid Carbide End Mills • Roughing
Series 49N6 • With Neck
• Centre cutting.
• Flat shallow profile.
• Standard items listed. Additional
styles and coatings made-to-order.
Detail X
Series 49N6 • With Neck
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance d11
-0,020/-0,080
-0,030/-0,105
-0,040/-0,130
-0,050/-0,160
-0,065/-0,195
D
)3
> 3–6
> 6–10
> 10–18
> 18–30
tolerance h6
+/-
0/-0,006
0/-0,008
0/-0,009
0/-0,011
0/-0,013
graAdelTAiNlT-MiNW-MW
AlTiN
order # catalogue #
3474583 49N604002MW
3474584 49N605002MW
3474585 49N606002MW
3474587 49N608003MW
3474589 49N610004MW
3474591 49N612005MW
3474593 49N614014MW
3474594 49N616006MW
3474595 49N618018MW
3474596 49N620007MW
3474597 49N625008MW
D1
4,0
5,0
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
25,0
D
6
6
6
8
10
12
14
16
18
20
25
first choice
alternate choice
length of cut
D3 Ap1 max
length
L3 L BCH
ZU
—
8,00
8,00 57 0,30
3
—
13,00
13,00
57
0,30
3
6
13,00
21,00
57
0,30
3
8
16,00
27,00
63
0,30
3
10
22,00
32,00
72
0,50
4
11
26,00
38,00
83
0,50
4
13
26,00
38,00
83
0,50
4
15
32,00
44,00
92
0,50
4
17
32,00
44,00
92
0,50
4
19
38,00
54,00
104
0,50
4
24
45,00
65,00
121
0,50
5
