High-Performance Solid Carbide End Mills • Hard Materials
Series 422869 422868 • Vision Plus™
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Series 422869 422868 • Vision Plus
gradKe10KU1F0-UDFC-DHCPHP
AlTiN
order # catalogue #
2343179 422869-000010
2343183 422869-000020
2343186 422869-000030
2343188 422869-000040
2343190 422869-000050
2343169 422868-000060
2343192 422869-000060
2343171 422868-000080
2343194 422869-000080
2343173 422868-000100
2343196 422869-000100
2343198 422869-000120
2343200 422869-000160
D1
1,0
2,0
3,0
4,0
5,0
6,0
6,0
8,0
8,0
10,0
10,0
12,0
16,0
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h8
+/-
D
0/0,014
)3
0/0,018
> 3–6
0/0,022
> 6–10
0/0,027
> 10–18
0/0,033
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
length of cut
length
D Ap1 max
L BETA
4 1,00
40 7.50
6 2,00
45 7.50
6 3,00
45 7.50
6 4,00
45 7.50
6 5,00
50 7.50
6 6,00
80 —
6 6,00
50 —
8 8,00
90 —
8 8,00
60 —
10 10,00
100 —
10 10,00
70 —
12 12,00
75 —
16 16,00
80 —
