High-Performance Solid Carbide End Mills • Hard Materials
Series 422870 • Vision Plus™
• Centre cutting.
• Standard items listed. Additional styles
and coatings made-to-order.
Diameter 4mm
Series 422870 • Vision Plus
D1
)3
> 3–6
> 6–10
> 10–18
> 18–30
End Mill Tolerances
tolerance h8
+/-
D
0/0,014
)3
0/0,018
> 3–6
0/0,022
> 6–10
0/0,027
> 10–18
0/0,033
> 18–30
tolerance h6
+/-
0/0,006
0/0,008
0/0,009
0/0,011
0/0,013
first choice
alternate choice
graKde10KU1F0-UDFC-HDPCHP
AlTiN
order # catalogue #
D1 D
length of cut
length
D3 Ap1 max L3
L
2343202 422870-000020
2,0
6
1,90
2,00
17,50
70
2343204 422870-000030
3,0
6
2,90
3,00
18,50
70
2343206 422870-000040
4,0
6
3,80
4,00
19,50
80
2343208 422870-000050
5,0
6
4,80
5,00
39,00
80
2343210 422870-000060
6,0
6
5,80
6,00
42,00
80
2343212 422870-000080
8,0
8
7,80
8,00
52,00
90
2343214 422870-000100 10,0 10
9,70
10,00
58,00
100
2343216 422870-000120 12,0 12 11,70
12,00
63,00
110
O178
