General Purpose Solid Carbide End Mills • Roughing/Finishing

Series 423048 423047 • NINA™

• Centre cutting.

• Standard items listed. Additional styles

and coatings made-to-order.

Series 423048 423047 • NINA

D1

)3

> 3–6

> 6–10

> 10–18

> 18–30

End Mill Tolerances

tolerance h10

+/-

D

0/0,04

)3

0/0,048

> 3–6

0/0,058

> 6–10

0/0,070

> 10–18

0/0,084

> 18–30

tolerance h6

+/-

0/0,006

0/0,008

0/0,009

0/0,011

0/0,013

first choice

alternate choice

graKde30KF3-0DFC-HDCHP

TiAlN

order # catalogue #

graKde30KF3-0DFC-HDPCHP

TiAlN

order # catalogue #

length of cut

length

D1 D

Ap1 max

L R

2343564 423048-000020

2343548 423047-000020

2,0

6

4,00

38 0,50

2343566 423048-000030

2343550 423047-000030

3,0

6

5,00

38 0,50

2343568 423048-000040

2343552 423047-000040

4,0

6

7,00

38 0,50

2343570 423048-000050

2343554 423047-000050

5,0

6

8,00

38 0,50

2343572 423048-000060

2343556 423047-000060

6,0

6

8,00

38 1,00

2343574 423048-000080

2343558 423047-000080

8,0

8

11,00

43 2,00

2343576 423048-000100 2343560 423047-000100 10,0 10

13,00
